Product model	TT2
Driving style	Side drive
Fuel category	diesel
Engine model	Yunnei4102
Engine power	66.2KW(90hp)
gearbox mode	545(12-speed high and low speed)
rear axle	DF1092
front axle	SL2058
Driv ing type	four drive
Braking method	automatically air-cut brake
Front wheel track	1800mm
Rear wheel track	1800mm
wheelbase	2350mm
frame	height  140mm * width 60mm * thickness10mm,
Unloading method	Rear  unloading  double  support  130*2000mm
front model	750-16wire tire
rear model	750-16 wire tire(double tire)
overall dimension	Lenght4800mm*width1800mm*height1900mm Height of the held 2.3m
tanker   dimension	Length2800mm*width1300mm*heght900mm
tanker plate thickness	5mm
Refueling system	Electrical control measurement
tanker  volume(m³)	2.4
oad capacity /ton	2
Exhaust gas treatment method,	Front water purifier

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.With a tank volume of 2.4 cubic meters, the TT2 can carry a load capacity of 2 tons. The tanker is equipped with an electrical control measurement system for accurate and convenient refueling. The overall dimensions of the TT2 are 4800mm in length, 1800mm in width, and 1900mm in height, with a shed height of 2.3 meters. The tanker dimension is 2800mm in length, 1300mm in width, and 900mm in height, with a plate thickness of 5mm.To ensure environmental compliance, the TT2 refueling truck is equipped with a front water purifier for exhaust gas treatment. This makes it an efficient and eco-friendly choice for refueling operations.The TT2 refueling truck has a sturdy frame with a height of 140mm, width of 60mm, and thickness of 10mm, providing strength and durability. The rear unloading double support mechanism with dimensions of 130*2000mm allows for efficient and safe unloading.
