Product model	MT6
Fuel category	diesel
Engine model	yunnei490
Engine power	46KW(63hp)
gearbox mode	530(12-speed high and low speed)
rear axle	DF1092
front axle	SL179
Drive mode,	rear drive
Braking method	automatically air-cut brake
Front wheel track	1630mm
Rear wheel track	1770mm
wheelbase	2400mm
frame	Main beam: height  120mm * width60mm *  thickness 8mm, Bottom beam: height 80mm * width 60mm * thickness 6mm
Unloading method	rear unloading  90*800mm  double su ppo rt
front model	700-16wire tire
rear mode	700-16 wire tire (double  tire)
overall dimension	Lenght4800mm*width1770mm*height1500mm Height of the shed 1.9m
cargo box dimension	Length3000mm*width1650mm*heght600mm
cargo box plate thickness	Bottom  8mm  side  5mm
steering system	Hydraulic ste ering
Leaf springs	Front  leaf  springs:9pieces*width70mm*thickness10mm Rear  leaf  springs:13pieces*width70mm*thickness12mm
cargo box volume(m³)	3
oad capacity /ton	6
Climbing ability	12°
Ground clearance	180mm
Displacement	2.54L(2540CC)

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.automatic air-cut brakes, and a robust chassis with a ground clearance of 180mm, making it suitable for handling challenging terrains. With a cargo box volume of 3 cubic meters and a load capacity of 6 tons, it is well-equipped to handle various hauling needs.This is our self-developed MT6 mining dump truck, which is designed for carrying and unloading tasks in mining and industrial environments. The vehicle boasts a powerful Yunnei490 diesel engine with 46KW (63hp) of output, and it operates with a 12-speed high and low-speed gearbox. The truck features rear-wheel drive,
