Product  model	MT18
Driving style	Side drive spring seat height of seat 1300mm
Fuel category	Diesel
Engine  model	XIchai 6110
Engine  power	155KW(210hp)
gearbox  model	10JS90 heavy 10 gear
Rear axle	Steyr slowdown Alxe
Front axle	Steyr
Driv ing type	Rear drive
Braking method	Automatically air-cut brake
Front wheel track	2250mm
Rear wheel track	2150mm
Wheelbase	3600mm
Frame	Height  200mm  *  width  60mm*  thickness10mm, 10mm steel plate reinforcement on both sides, with bottom beam
Unloading  method	Rear  unloading  double  support  130*1600mm
Front model	1000-20wire tire
Rear  mode	1000-20 wire tire(double tire)
Overall dimension	Lenght6300mm*width2250mm*height2150mm
Cargo box dimension	Length5500mm*width2100mm*heght950mm Channel steel cargo box
Cargo box plate thickness	Bottom  12mm  side  6mm
Ground clearance	320mm
Steering system	Mechanical   steering
Leaf springs	Front  leaf  springs:10pieces*width75mm*thickness15mm Rear  leaf  springs:13pieces*width90mm*thickness16mm
Cargo box volume(m³)	7.7
Climbi ng ability	12°
Oad capacity /ton	20
Exhaust gas treatment method,	Exhaust gas purifier
Minimum turning radius	320mm

1. What are the main models and specifications of your mining dump trucks? Our company produces various models and specifications of mining dump trucks, including large, medium, and small-sized ones. Each model has different loading capacities and dimensions to meet various mining requirements. 2. What types of ores and materials are your mining dump trucks suitable for? Our mining dump trucks are suitable for all types of ores and materials, including but not limited to coal, iron ore, copper ore, metallic ores, etc. They can also be used for transporting sand, soil, and other materials. 3. What type of engine is used in your mining dump trucks? Our mining dump trucks are equipped with efficient and reliable diesel engines, ensuring sufficient power and reliability even in harsh mining working conditions. 4. Does your mining dump truck have safety features? Yes, we place a high emphasis on safety. Our mining dump trucks are equipped with advanced safety features, including brake assistance, anti-lock braking system (ABS), stability control system, etc., to minimize the risk of accidents during operation.We offer a comprehensive after-sales service, including: 1. Provide customers with rich product use training and operation guidance to ensure that they can correctly operate and maintain dump trucks. 2. We provide comprehensive product training and operator instruction to ensure customers can confidently and accurately operate and maintain dump trucks. 3. We provide reliable, high-quality original spare parts and maintenance services to ensure your vehicle is always in top working condition. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.The unloading method is rear unloading with double support, with dimensions of 130mm by 1600mm. The front tires are 1000-20 wire tires, and the rear tires are 1000-20 wire tires with a double tire configuration. The overall dimensions of the truck are: Length 6300mm, Width 2250mm, Height 2150mm.The cargo box dimensions are: Length 5500mm, Width 2100mm, Height 950mm, and it is made of channel steel. The cargo box plate thickness is 12mm at the bottom and 6mm on the sides. The ground clearance of the truck is 320mm.The front wheel track measures 2250mm, while the rear wheel track is 2150mm, with a wheelbase of 3600mm. The truck's frame consists of a main beam with a height of 200mm, width 60mm, and thickness 10mm. There is also 10mm steel plate reinforcement on both sides, along with a bottom beam for added strength.The steering system is mechanical steering, and the truck is equipped with 10 front leaf springs with a width of 75mm and thickness of 15mm, as well as 13 rear leaf springs with a width of 90mm and thickness of 16mm. The cargo box has a volume of 7.7 cubic meters, and the truck has a climbing ability of up to 12°. It has a maximum load capacity of 20 tons and features an exhaust gas purifier for emission treatment. The minimum turning radius of the truck is 320mm.
