Product  model	MT10
Driving style	Side drive
Fuel category	Diesel
Engine  model	Yuchai4105 Supercharged engine
Engine  power	90KW(122hp)
Gearbox  model	545(12-speed high and low speed )
Rear axle	DF1098D(153)
Front axle	SL450
Braking method	Automatically air-cut brake
Front wheel track	2150mm
Rear wheel track	1900mm
Wheelbase	2650mm
Frame	Main beam: height  200mm * width60mm *  thickness  10mm, Bottom beam: height 80mm * width 60mm* thickness 8mm
Unloading  method	Rear unloading  double su ppo rt 110*950mm
Front model	825-16wire tire
Rear model	825-16 wire tire (double  tire)
overall dimension	Lenght5100mm*width2150mm*height1750mm height of the shed 2.1m
Cargo box dimension	Length3400mm*width2100mm*heght750mm
Cargo box plate thickness	Bottom  10mm  side 6m m
steering system	Mechanical  steering
Leaf springs	Front  leaf  springs:9pieces*width70mm*thickness12mm Rear  leaf  Springs:13pieces*width70mm*thickness15mm
cargo box volume(m³)	5
oad capacity /ton	12
Climbing ability	12°
Exhaust gas treatment method,	Exhaust gas purifier

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.The front tires are 825-16 wire tires, and the rear tires are 825-16 wire tires with a double tire configuration. The overall dimensions of the truck are: Length 5100mm, Width 2150mm, Height 1750mm, and the height of the shed is 2.1m. The cargo box dimensions are: Length 3400mm, Width 2100mm, Height 750mm. The cargo box plate thickness is 10mm at the bottom and 6mm on the sides.The truck's steering system is mechanical steering, and it is equipped with 9 front leaf springs with a width of 70mm and thickness of 12mm, as well as 13 rear leaf springs with a width of 70mm and thickness of 15mm. The cargo box volume is 5 cubic meters, and it has a load capacity of 12 tons. The truck can handle a climbing angle of up to 12°. Additionally, it features an exhaust gas purifier for emission treatment.The front wheel track measures 2150mm, while the rear wheel track is 1900mm, and the wheelbase is 2650mm. The truck's frame consists of a main beam with a height of 200mm, width of 60mm, and thickness of 10mm, as well as a bottom beam with a height of 80mm, width of 60mm, and thickness of 8mm. The unloading method is rear unloading with double support measuring 110*950mm.
