Product  model	EMT5
Cargo box Volume	2.3m³
Rated load capacity	5000kg
Unloading height	2800mm
loading height	1450mm
Ground clearance	Front axle 190mm Rear axle 300mm
Turning radius	<5200mm
Wheel track	1520mm
Wheelbase	2200mm
Climbing ability (heavy load)	≤8°
Maximum lift angle of the cargo box	40±2°
Lift motor	1300W
Tire model	Front tire 650-16(mine tire)/rear tire 750-16(mine tire)
Shock absorption system	Front: 7peces*70mm width *12mm thickness/ Rear:9pieces*70mmwidth     *12mmthickness
Operation   system	Medium plate(hydraulic steering)
Control   system	Intelligent controller
Lighting system	Front and rear LED lights
Maximum   Speed	25km /h
Motor  model/power	AC  10KW
No.Battery	18 pieces, 8V,150Ah maintenance-free
Voltage	72V
Overall dimension (	Length4100mm*Width1520mm*Height       14 50mm
Cargo  box  dimension(outer  diameter  )	Length2800mm*Width150     0m m*Height600mm
Cargo box plate thickness	Bottom 5mm     side 3mm
Frame	Rec ta ngular tube welding ,50mm*120mm double beam
Overall weight	2060kg

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.The lift motor has a power of 1300W, ensuring smooth and reliable operation of the lifting mechanism. The tire model consists of 650-16 mine tire for the front and 750-16 mine tire for the rear, providing excellent traction and durability in mining environments. For shock absorption, the front is equipped with 7 pieces of 70mm width and 12mm thickness springs, while the rear has 9 pieces of 70mm width and 12mm thickness springs, providing a comfortable and stable ride even over rough terrains.The EMT5 features a medium plate with hydraulic steering for precise control during operation, and an intelligent controller ensures efficient and user-friendly control of the truck. The lighting system includes front and rear LED lights for visibility during low-light conditions. The maximum speed of the EMT5 is 25km/h, allowing for efficient transportation of materials within mining sites. The truck is powered by an AC 10KW motor, driven by eighteen maintenance-free 8V, 150Ah batteries, providing a voltage of 72V.The EMT5 has a ground clearance of 190mm for the front axle and 300mm for the rear axle, allowing it to navigate uneven and rough terrains with ease. The turning radius is less than 5200mm, providing good maneuverability even in confined spaces. The wheel track is 1520mm, and the wheelbase is 2200mm, ensuring stability during operation. The truck has an excellent climbing ability of up to 8° when carrying a heavy load, allowing it to handle inclines on mining sites. The maximum lift angle of the cargo box is 40±2°, enabling efficient unloading of materials.The overall dimensions of the EMT5 are: Length 4100mm, Width 1520mm, Height 1450mm. The cargo box dimensions (outer diameter) are: Length 2800mm, Width 1500mm, Height 600mm, with a cargo box plate thickness of 5mm at the bottom and 3mm on the sides. The truck's frame is constructed using rectangular tube welding, featuring a 50mm*120mm double beam for strength and durability. The overall weight of the EMT5 is 2060kg, and with its robust design, high load capacity, and reliable performance, it is an excellent choice for heavy-duty material transportation in mining operations.
