Project	Parameter
Standard   bucket(SAE)	10m 3
Rated  load	20000Kg
The Angle of hopper unloading	≥65°
Approach  angle	≥15°
No load weight	19500Kg
Fullload  lift  time	15s
Angle of oscillation	±8°
climbing  capacity	≥15°
minimum turning radius	7800  ±  200(outside)
Gear	Grade  I:0-5  Km/h
	Level  II:0-9  Km/h
	Grade  III:0-15  Km/h
	The  IV  gear:0-18.5Km/h
Torque-converter	DANA CL5400
Power  transmission	DANA R36000
Banjo  axle	Spring-brake  hydraulic release of the rigid drive axle DANA 17D
Brake  assembly	Spring brake, hydraulicrelease
Engine model number / power	VOLVO TAD1150VE /235Kw
Overall  dimensions(length  x width x height)	9080x2280x2450(Cab   height)

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.Angle of oscillation: The truck has an oscillation angle of ±8°, providing increased flexibility for maneuvering in confined work areas. Climbing capacity: The truck demonstrates good climbing capacity, capable of handling slopes with an inclination of ≥15°, maintaining steady progress. Minimum turning radius: The truck has a minimum turning radius of 7800 ± 200 millimeters (outside), enabling it to perform agile turns in limited spaces.Gear system: The truck is equipped with a multi-speed gear system, including Gear I (0-5 km/h), Gear II (0-9 km/h), Gear III (0-15 km/h), and Gear IV (0-18.5 km/h), allowing for the selection of appropriate speeds for different working conditions. Torque converter: Utilizing the DANA CL5400 torque converter, it provides excellent power transmission efficiency, ensuring smooth and efficient operation under various load conditions. Power transmission: The truck employs the DANA R36000 power transmission system, guaranteeing power delivery from the engine to the wheels, maintaining good traction and power output.Approach angle: The truck has an approach angle of ≥15°, enabling it to adapt easily to different terrains and road conditions, ensuring stable driving and maneuverability. No load weight: The truck's empty weight is 19,500 kilograms, which is important as a reference for calculating the payload and cargo distribution. Full load lift time: The truck can complete its full load lift operation within 15 seconds, indicating high efficiency in unloading operations.Banjo axle system: The truck features the DANA 17D articulated axle system with spring brakes and hydraulic release, ensuring stability and safety during operation. Brake assembly: Equipped with spring brake and hydraulic release brake assembly, the truck provides reliable braking performance for enhanced safety during driving. Engine model/power: The truck is powered by the VOLVO TAD1150VE engine with 235 kW of robust power output, capable of handling various workloads.Overall dimensions: The truck's overall dimensions are 9080 millimeters (length) x 2280 millimeters (width) x 2450 millimeters (height, including the cab height). These dimensions allow the truck to navigate easily in construction sites, mines, or other narrow environments. Overall, this articulated truck combines robust carrying capacity, efficient unloading speed, excellent maneuverability, and adaptability to various terrains, making it a highly practical and reliable transportation tool. Whether it's in construction sites, mining areas, or other cargo transportation scenarios, this truck excels in its performance.
